商品型錄

Name: SOCKET 1/2"
Brand: BAHCO
SKU: SB7800TORX-E11

正在載入商品資料…

SB7800TORX-E11

1/2" Square Drive Socket with E11 TORX® Profile Retail Pack

SOCKET 1/2"

BAHCO

型號	Size	Length L	Socket width	Female square drive width	Depth ball-bearing	Screw	Weight, g
SB7800TORX-E11	E11	38 mm	15.4 mm	22 mm	7.6 mm	-	60 g

型號	Size	Length L	Socket width	Depth ball-bearing	Screw	Weight, g	Female square drive width	價格
7800TORX-E10	E10	38 mm	14.2 mm	7.1 mm	M8	60 g	—	價格請洽詢
7800TORX-E11	E11	38 mm	15.4 mm	7.6 mm	-	70 g	22 mm	價格請洽詢
7800TORX-E12	E12	38 mm	15.4 mm	8.2 mm	M8+ M10	60 g	22 mm	價格請洽詢
7800TORX-E14	E14	38 mm	16.6 mm	9.5 mm	M10+M12	80 g	22 mm	價格請洽詢
7800TORX-E16	E16	38 mm	19.1 mm	10.8 mm	-	60 g	22 mm	價格請洽詢
7800TORX-E18	E18	38 mm	20.4 mm	12 mm	M12+M14	70 g	22 mm	價格請洽詢
7800TORX-E20	E20	38 mm	22.9 mm	13.3 mm	M14+M16	80 g	22.9 mm	價格請洽詢
7800TORX-E24	E24	38 mm	27.9 mm	16 mm	M18+M20	90 g	25 mm	價格請洽詢
7800TORX-E8	E8	38 mm	10.7 mm	6 mm	-	60 g	22 mm	價格請洽詢
SB7800TORX-E10	E10	38 mm	14.2 mm	7.1 mm	M8	70 g	—	價格請洽詢
SB7800TORX-E11本商品	E11	38 mm	15.4 mm	7.6 mm	-	60 g	22 mm	價格請洽詢
SB7800TORX-E12	E12	38 mm	13.5 mm	8.2 mm	M8+M10	70 g	22 mm	價格請洽詢
SB7800TORX-E14	E14	38 mm	16.6 mm	9.5 mm	M10+M12	60 g	22 mm	價格請洽詢
SB7800TORX-E16	E16	38 mm	19.1 mm	10.8 mm	-	70 g	22 mm	價格請洽詢
SB7800TORX-E18	E18	38 mm	20.4 mm	12 mm	M12+M14	60 g	22 mm	價格請洽詢
SB7800TORX-E20	E20	36 mm	22.9 mm	13.3 mm	M14+M16	80 g	22.9 mm	價格請洽詢
SB7800TORX-E24	E24	37 mm	27.9 mm	16 mm	M18+M20	100 g	25 mm	價格請洽詢
SB7800TORX-E8	E8	36 mm	10.7 mm	6 mm	-	80 g	22 mm	價格請洽詢

填入所需數量後，一次加入詢價清單。交期與專案價格請洽詢。

已填 0 項 · 共 0 件
